KRYO560 controlled rate freezer
Simple to programme and easy to operate.
This rugged and reliable controlled rate freezer has a top opening chamber, which uses turbulent flow system, conducive with rapid mixing and superior thermal transfer ensuring excellent temperature control in all phases of the protocol. Planer’s MRV Controller system offers multiple protocol availability.
The -180ºC end temperature ensures sample integrity during transfer to storage at liquid nitrogen temperatures whilst the flexibility of the system, including protocol stage transition based on sample or chamber temperature or time, is ideal for the more demanding protocols associated with advanced cryo-preservation techniques.
Benefits
Freezes samples in bags, vials and straws
Validation offered via Controller password controlled access on multiple user levels
Menu driven controller, simple to operate
Displays demand, sample and chamber temperatures
Displays alphanumerically and graphically via an easy view display
Trigger on sample, time or temperature
Top opening chamber; lid is kept warm to prevent freezing shut at cryogenic temperatures
Run print out via integral full view printer
Time and date stamping, programme preview/verification before running
Features
Chamber volume: 16 litres
Capacity: 11 x 250/500/750ml bags, horizontally or vertically in chamber
48 x 25ml PALL bags
Vial or ampoule capacity: 726 x 2ml in baskets
Straw capacity: 608 x 2ml on canes (horizontal)
Lower temperature limit: -180ºC
Cooling rates: -0.01 to -50ºC/Min
Controlled heating rates:0.01 to 10ºC/Min
Controlled heating; start above ambient
Data Printing (integral printer); Comms port for PC connection
System controller: Planer's MRV
System Pump: Planer's LNP4
System Dewar: Chart LAB 30
